- Size: 21.5x17x15cm
- Place of Origin: china
- Brand Name: weili
- Model Number: hsz
- Weight: 20.000 kg
BODY & HOOK: YELLOW
GUIDE ROLLER:Machining/Black oxidation
Stripper/Anchorage:Casting/Black oxidation
Hand Chain: White Zinc Plate
Load Chain:Black Oxidation
Hook Latch: Color Galvanized
Side Plate: VT yellow
Hand Chain Wheel: Casting & Black electropheris
Load Sheave: Ductil Cast Iron
Packing 1t-5t In Carton; 10t or above plywood case
Manual & QC certificate: Neutral
Anchor plate avoiding over down.
Wet Friction discs with longer lift.
Gear case and hand wheel cover resistant to external shocks.
Meets requirement of EN13157.
Double pawl supporting brake mechanism.
Load sheave with sealed roller bearing or bush option.
Forged and heat treated load hooks.
- Size: 21.5x17x15cm
- Place of Origin: china
- Brand Name: weili
- Model Number: hsz
- Weight: 20.000 kg
vital type chain block specifications
| Model | VT1/2 | VT-1 | VT-2 | VT-3 | VT-5 | VT-10 |
| Capacity(t) | 0.5 | 1 | 2 | 3 | 5 | 10 |
| Lifting Height(m) | 2.5 | 2.5 | 3 | 3 | 3 | 3 |
| Test load(t) | 0.75 | 1.5 | 3 | 4.5 | 7.5 | 15 |
Hmin Headroom(mm) | 285 | 315 | 380 | 475 | 600 | 700 |
| Chainpull to lift full load(N) | 25 | 33 | 34 | 35 | 39 | 41 |
| No. of load chain | 1 | 1 | 1 | 2 | 2 | 4 |
| Diameter of load chain | 6.1 | 7.1 | 8 | 7.1 | 9 | 9 |
| N.W(kg) | 8.4 | 11 | 21 | 22 | 40 | 77 |
